TECHNISTAR S2 Int. Edition Receiver Software, Tools


TECHNISTAR S2 Int. Edition

High Defenition Digital Satellite Receiver

TECHNISTAR S2 Black Receiver Software, Tools

TECHNISTAR S2 Black Receiver Software, Tools

TECHNISTAR S2 Black Receiver Software, Tools

Technical Data

EAN4019588647398 Item no.0006/4739
Weight600 g Weight (Box)1.6 kg
Device (W x H x D)28.00 x 3.70 x 13.50 cm Box39.50 x 5.60 x 21.50 cm

HDMI (out)1 Common Interface Plus (CI+)1
Smartcard reader1
Digital electric audio output1
Audio out analogue1 (rechts / links)
Scart1 Ethernet 10/100 (RJ-45)1 F socket1
Connector for external IR-Receiver1
Decryption system

Conax  CI+

Humidity10 … 75 % Ambient temperature5 … 35 °C

Vertical power supply14 V Horizontal power supply18 V
LNB modulation22 kHz LNB power supplymax.
400 mA (kurzschlussfest) DiSEqC1.0 / 1.2

Total programme memory4000
Sleep timer  Alarm  OSD languages
Danish, German, English, French, Italian, Dutch, Norwegian, Polish, Portuguese, Slovakian, Swedish, Spanish, Czech, Hungarian
Picture functions

Freeze frame  Zoom
Power consumption

Standby LED< 0.5 W In operation7.5 W
Power supply

Nominal voltage230 V Frequency50 Hz Mains adapterextern DC 12V/1,5A

USB1 (USB 2.0)
Supported formats & codecs

Audio-FormatsMP3, MP2
Picture-FormatsJPEG Video-CodecsMPEG-2
Video-FormatsTS, TS4, VOB

Tuner typeDigitalSat Reception onHDTV (MPEG-4 & 2), SD (MPEG-2) Input impedance75 O
Demultiplexinggemäß ISO 13818-1 DVB-S tuner1
Reception range950 … 2150 MHz Viterbi rates1/2, 2/3, 3/4, 5/6, 7/8 , (autom. Anpassung) DVB-SQPSK DVB-S2 … 45
Mbaud DVB-S28PSK – QPSK DVB-S210 … 31 Mbaud FECViterbi and Reed-Solomon
Tuner (DVB-S)

Single Cable Solution (SatCR)SCR1 = EN50494

TECHNISTAR S2 Int User Manual

TECHNISTAR S2 Int Date Sheet

TECHNISTAR S2 Int Device Software

Ver_2.46.13.7-1940v 20-03-2017

TECHNISTAR S2 Int Beta Software

Ver_3.6.15 11-01-2013
